Key Points of Process Control for Stretching Hydraulic Presses

Today, Jianlong Hydraulic Technology will further share the key points of process control for general-purpose stretching hydraulic presses for your reference!

1. Speed Control

1.1 Idle Speed: Rapid descent for improved efficiency, typically ≥120mm/s

1.2 Feed Speed: Slow stretching to ensure quality, typically 5-25mm/s

1.3 Speed Switching: Automatic switching between fast and slow speeds via proximity switch

2. Pressure Control

2.1 Stretching Force: Main cylinder pressure, set according to material thickness and stretching depth

2.2 Blank Holder Force: Infinitely adjustable via hydraulic cushion to prevent wrinkling, typically 20%-40% of the main cylinder pressure

2.3 Holding Time: Adjustable from 0-999 seconds to ensure material plastic deformation

3. Position Control

3.1 Stroke Control: Precise control of the slider's bottom dead center position via displacement encoder

3.2 Repeatability: ≤±0.1mm, ensuring product consistency

4. Process Mode Selection

4.1 Constant Pressure Forming: Stops when pressure reaches the set value, suitable for pressure-sensitive processes

4.2 Fixed-stroke forming: The slider stops when it reaches the set position, suitable for processes with strict dimensional requirements.

For more information/advice on stretching hydraulic presses or to purchase other high-quality hydraulic presses, please contact us (or scan the WhatsApp QR code below). Jianlong Hydraulic Technology will provide you with personalized and customized professional solutions and is dedicated to serving you.
